Part Number : T30
Product Introduction :
Avlock India's lockbolt hydraulic installation tool range are high performance and light-weight. Use of Avlock tool reduces operator fatigue by it ergonomic and user-friendly design. The Avlock tool range in becoming a necessary requirement in every workshop and assembly line due to its durability and low noise mechanism feature.
Specifications :
HYDRADRIVE INSTALLATION TOOLS | |||
MODEL NO | T30 | ||
LOCKBOLTS SIZE | 1/2”-3/4” | ||
A mm | 143 - 145 | ||
B mm | 91 - 93 | ||
C mm | 183 - 185 | ||
WEIGHT kg | 8 |
NOSE ASSEMBLY | |||
MODEL NO | N32 | N31 | N32 |
LOCKBOLTS SIZE | 1/2” | 5/8” | 3/4” |
L mm | 110 | 113 | 131 |
N mm | 43 | 48 | 56 |
WEIGHT kg | 1.4 | 1.4 | 1.6 |
SUITABLE TOOL | T30 | T30 | T30 |
