A3000-02000 - Hydro - Pneumatic Riveting Tool

A3000-02000 - Hydro - Pneumatic Riveting Tool

A3000-02000 - Hydro - Pneumatic Riveting Tool

Specifications :

Air Pressure Minimum - Maximum 5-7 bar
Free Air Volume Required   5.5 bar 4.3 liters
Stroke Minimum 26mm
Pull Force  5.5 bar 12.9 kN
Cycle time Approximately 1.2 second
Noise Level   75 dB(A)
Weight Without nose equipment 1.64 kg
Vibration Less than 2.5 m/s2
 Material – Aluminium/ Steel/Stainless Steel
 Size – 3.2 mm to 6.4 mm Breakstem Rivets



Types of A3000-02000 - Hydro - Pneumatic Riveting Tool

Video Of A3000-02000 - Hydro - Pneumatic Riveting Tool

A3000-02000 Hydro - Pneumatic Riveting Tool


Model No
Material
Size

Min Max
Air Pressure

Min Max
Free Air Volume Required @ 5.5 bar
Stroke Min.
Pull Force @ 5.5 bar
Cycle time Approximately
Noise Level
Weight Without nose equipment
Vibration Less than
A3000-02000
Aluminium/ Steel/ Stainless Steel
3.2 mm 6.4 mm
5 bar 7 bar
4.3 liters
26 mm
12.9 kN
1.2 second
75 dB(A)
1.64 kg
2.5 m/s2
